_{vuejs/core#2532 · 11 files · +1,081/−670 · 3 lanes. <script setup> and the original ref sugar.}

_{rust-lang/rust#31954 · 26 files · +369/−16 · 4 lanes. The postfix ? operator, chainable shorthand for try!.}

_{tokio-rs/tokio#1657 · 100 files · +7,408/−6,795 · 3 lanes. The work-stealing pool rebuilt to cut scheduler overhead.}

_{neovim/neovim#11336 · 15 files · +5,556/−1 · 3 lanes. The LSP client moves into Neovim itself.}

_{django/django#11209 · 38 files · +931/−42 · 5 lanes. An ASGI handler and a coroutine-safe request context.}

_{webpack/webpack#10440 · 13 files · +567/−5 · 5 lanes. ContainerPlugin, and module federation with it.}

_{vllm-project/vllm#1348 · 6 files · +764/−139 · 3 lanes. PagedAttention V2 and its sequence-level parallelism.}

Your agent is usually already the model. Rather than spending a provider key to describe a diff it already understands, it writes the graph document itself and lets the validator hold it to the contract.

npx skills add coldteadotai/pr-lens

Then say, literally:

Diagram the change you just made with PR Lens and attach it to the pull request.

The agent reads the diff, writes the document, runs npx @coldtea/pr-lens-cli validate until the contract is satisfied, renders, and puts the diagram in the pull request description with gh pr create --attach, so it lands with the change instead of behind it. If a diagram names things wrongly, the same skill teaches it to fix .github/pr-lens.yml instead of editing generated output. Details in packages/agent-skill.

Prefer to have the agent do the whole setup? Paste this:

Set up PR Lens (prlens.dev) for me: it draws each pull request as animated architecture and data-flow diagrams, inside the pull request itself.

1. Install the agent skill: `npx skills add coldteadotai/pr-lens`.

2. Walk me through installing the GitHub App at https://github.com/apps/coldtea-pr-lens on every repository where I review pull requests. It posts one sticky comment per pull request and updates it on every push, with no model key of mine involved.

3. If I'd rather run it from CI with a model key of mine, offer the Action instead: `.github/workflows/pr-lens.yml` using `coldteadotai/pr-lens/packages/action@v0`, with the key as a repository secret. It takes Gemini by default, OpenAI, or any endpoint speaking `/chat/completions`.

4. Then prove it: diagram the most recent change in this repository and show me the rendered SVGs.

The same comment from your own CI, drawn with your own model key. Add that key as a repository secret — GEMINI_API_KEY below, because provider defaults to Gemini — then commit this as .github/workflows/pr-lens.yml:

name: PR Lens

on:
  pull_request:

permissions:
  contents: write # to publish the rendered SVGs
  pull-requests: write # to post the comment

concurrency: # one run per pull request; a push supersedes the last
  group: pr-lens-${{ github.event.pull_request.number }}
  cancel-in-progress: true

jobs:
  lens:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
        with:
          fetch-depth: 0 # the diff is between two commits, so both must be here
      - uses: coldteadotai/pr-lens/packages/action@v0
        with:
          api-key: ${{ secrets.GEMINI_API_KEY }}

Nothing here is tied to one model. provider takes gemini (the default), openai, or openai-compatible with a base-url and model, so the same workflow runs against OpenRouter, DeepSeek or a server of your own. The key reaches the CLI through the environment, never a command line, and the diff goes to the provider you name and nowhere else. The comment here is deliberately static — an Action cannot hold state between runs, so the checkboxes live in the App. Providers, lenses, branding and the rest of the inputs are in packages/action.

Everything the other modes do, one step at a time, on your machine. Only analyze talks to a model, and its key is read from the environment, never from a flag:

export GEMINI_API_KEY=…    # the default provider; OPENAI_API_KEY with --provider openai

# Diff in, graph document out — measured against the merge base, not the branch tip.
npx @coldtea/pr-lens-cli analyze --base origin/main

# The document as light and dark SVGs, plus the manifest a comment is built from.
npx @coldtea/pr-lens-cli render .pr-lens/graph.json

# The pull request comment as markdown, on stdout. Posting is your business.
npx @coldtea/pr-lens-cli comment --graph .pr-lens/drawn.graph.json --manifest .pr-lens/manifest.json \
  --asset-base-url https://raw.githubusercontent.com/owner/repo/pr-lens/42

# Any PR Lens document, checked against the contract — every problem, not just the first.
npx @coldtea/pr-lens-cli validate .pr-lens/graph.json .github/pr-lens.yml

# After the merge: the pull-request document as a stored map of the system, worth committing.
npx @coldtea/pr-lens-cli export .pr-lens/graph.json -o .github/pr-lens.map.json

Everything lands in .pr-lens/, which the CLI adds to your .gitignore the first time it writes there. Treat it as scratch: the files are rebuilt from the diff on demand, and the only one worth committing is the map export writes. --out puts them somewhere else if you would rather.

Ollama, DeepSeek, OpenRouter and anything else speaking /chat/completions are reached with --provider openai-compatible --base-url <url>. The full command reference, the correction file, and the failure codes a script can branch on are in packages/cli.

Nothing about the diagrams needs a pull request. Render locally and look at the change before anyone else does:

npx @coldtea/pr-lens-cli analyze --base origin/main
npx @coldtea/pr-lens-cli render .pr-lens/graph.json
open .pr-lens/*-dark-*.svg    # macOS; the SVGs are self-contained, any browser reads them

This is also the shape of reviewing an agent's work: while you read the diff, the agent that wrote it renders it. With the skill installed, "render this change with PR Lens and open the SVGs" gets you the diagram beside the diff, the same picture its pull request will carry, minutes earlier.
